Technical Specifications of Asphalt Mixing Plant
(For more customized models, please contact us)
| LB1000 | LB1500 | LB3000 | LB5000 | |
| Theoretical Production Capacity | 80t/h | 130t/h | ||
| 料仓总容量Total Storage Bin Capacity | 150t (30t × 5) | |||
| 提升机功率Elevator Power | 30kW | |||
| 配料斗体积Batching Hopper Volume | 4 × 9.5m³ | |||
| 烘干滚筒 Drying Drum | φ1.8 × 8m | |||
| 燃烧器Burner | 4.7 × 5.5kW | |||
| 一级除尘器Primary Dust Collector | Gravity Dust Collector | |||
| 二级除尘器Secondary Dust Collector | Bag Filter (408 Filter Bags) | |||
| 筛网尺寸Screen Mesh Size | 4 Layers | |||
| 搅拌电机Mixing Motor | 2 × 30kW | |||
| 搅拌缸尺寸Mixing Tank Size | 5.5×1.6×1.6 / 5.1×1.5×2.6 / 6.2×2.5 | |||
| 沥青泵 Bitumen Pump | 4kW | |||
| 管道 Pipeline | φ76 | |||
| 导热油炉 Thermal Oil Heater | 1 × 500 (Vertical/Horizontal Optional) | |||
| 沥青保温罐 Bitumen Storage Tank | 40 / 75 m³ |
